TecMate TM631 OptiMate™ 4 Quad Program

The OptiMate 4 Quad Program (TM631) is TecMate's most advanced power-sport battery charger, engineered for high-technology 12V and 12.8V batteries in adventure, touring, cruiser, and performance motorcycles, as well as ATVs, side-by-sides, and personal watercraft. Its four selectable charging programs let you charge a battery directly, through a live (hot) 12V socket, or through a BMW CAN-bus controlled 12V socket. Just select by battery type and connection method — the OptiMate does the rest, fully automatically, with no supervision required.

This Gold Series 9-step charger tests battery health before and after charging and can recover a "dead-flat" lead-acid or lithium (LiFePO4) battery from as low as 0.5V. Built into an IP54 weatherproof case rated for use down to -40°, it's safe to leave connected long-term to keep your battery at full charge and in good health.

Key Features

• Quad Program – four selectable charging modes for 12V lead-acid and 12.8V/13.2V lithium (LiFePO4) batteries
• Program 1 or 3: charge battery direct or through a live (hot) 12V socket (e.g. Triumph)
• Program 2 or 4: charge through a BMW CAN-bus controlled 12V socket (optional cable accessory required)
• Gold Series 9-step charging: 1.25A sealed charger and maintainer
• Smart desulphation from 0.5V for lead-acid batteries
• Low-volt recovery & BMS reset for lithium LFP batteries
• Recovers dead-flat batteries from as low as 0.5V
• Tests battery state of health before and after charging
• Fully automatic, multi-step program — no supervision required
• Safe to leave connected with full electronic protection
• Maintains battery at full charge and good health
• IP54 weatherproof case with wall mounts
• Rated for use down to -40°C / -40°F, indoor or outdoor

Specifications

• Model: TM631
• Series: Gold Series, 9-step
• Charge current: 1.25A
• Battery types: 12V AGM, GEL & STD lead-acid; 12.8V/13.2V lithium (LiFePO4)
• Lead-acid capacity range: 4–60Ah
• Lithium capacity range: 2–15Ah
• Charge programs: 4 selectable (12V smart desulphation 0.5V–14.4V; 12V BMW CAN-bus 5V–14.4V; 12.8V low-volt recovery 0.5V–14.4V; 12.8V BMW CAN-bus 8.8V–14.4V)
• Input: Global 100–240V, 50–60Hz, high efficiency (CEC listed)
• Weatherproof rating: IP54
• Operating temperature: down to -40°C / -40°F
• AC supply lead: 6 ft / 180 cm
• Charge lead: 6 ft / 180 cm, ending in SAE connector
• Includes: battery clip cable and ring terminal (eyelet) harness, wall mount
